Merida Crossway 10 V Lady Hybrid Bicycle
A62211A00874
Merida Crossway 10 V Lady Hybrid Bicycle - Your Reliable Companion for Town and Cross Country Rides
Experience the perfect blend of reliability, versatility, and comfort with the Merida Crossway 10 V Lady Hybrid Bicycle. This entry-level trekking/hybrid bike is equipped with reliable V-brakes and suspension forks, making it an excellent choice for riders seeking an affordable and dependable ride around town and on cross country adventures.
Reliable Performance at an Attractive Price
- Lightweight aluminium frame with comfort geometry ensures a comfortable and enjoyable riding experience
- Powerful and easy-to-service V-brakes provide reliable stopping power and enhanced safety
- Suspension fork and seat post offer extra comfort and ensure a smooth ride over various terrains
Versatility for Your Adventures
- Broad gear range enables quick and efficient rides, allowing you to reach your destination swiftly and conquer steeper slopes with ease
- Suitable for fitness training, commuting, and leisurely rides through forests and trails
- Multiple fixing points for rear rack and fenders, providing convenience for carrying your essentials
Designed for Comfort and Enjoyment
- Adjustable stem allows you to find the perfect riding position, enhancing your overall comfort
- Lightweight aluminium construction offers durability without compromising on agility
- Fitted with 700c wheels and 40 mm wide tyres, providing puncture protection, excellent grip, and a smooth and comfortable ride
The Crossway Experience
For years, the Crossway family has been the backbone of the Merida range, trusted by riders worldwide. Designed to provide a comfortable and enjoyable riding experience, the Crossway 10 V Lady Hybrid Bicycle offers the perfect blend of functionality, versatility, and reliability. Whether you're commuting, training, or exploring nature, this bike is your ideal companion.
Specifications
Specifications of Merida Crossway 10 V Lady Hybrid Bicycle
Frame | Crossway L DT (material: aluminium, 700x42C max. Wheelsize, 135x9mm Axle Standard, BSA Bottom Bracket Standard) |
Frame Size | XS, S |
Color | Silk Dark Silver (Grey/Black) & Blue (Steel Blue/White) |
Fork | Suntour NEX (Coil; 63mm Suspension Travel; 700x50C max. Wheelsize) |
Brakes | Promax MTV-117A |
Headset | FSA TH888 |
Handlebar | Merida CC (material: Steel; 620mm Width, 30mm Rise) |
Handlebar Stem | Merida TK (material: aluminium, 25.4 diameter, adjustable, 100mm) |
Grip | Merida EC |
Derailleur | Front: Shimano FD-TY510; Rear: Shimano RD-M310 |
Shifters | Shimano ST-EF500 |
Seatpost | Merida TK (27.2mm diameter, 13mm setback, 40mm seatpost suspension travel) |
Seatclamp | Merida Comp QR |
Saddle | Merida Cross Sport |
Pedal | VP VPE-891 |
Chain | KMC NS8 |
Chainwheel |
Shimano TY301 (48-38-28 Teeth; 170mm-XXS/SM, 175 mm-ML/XXL) |
Crank | 170 mm-XXS/SM, 175 mm-ML/XXL |
Freewheel | Shimano MF-TZ500 (14-28 Teeth, 7 speed) |
Bottom Bracket | FSA TH-7420ST-W, Cartridge Bearing |
Hubs | Joytech JY-751DSE / Joytech JY-752DSE (100x9mm width front hub, 32 spoke holes; 135x9mm width rear hub, 32 spoke holes) |
Rim | Merida CC (17mm inner width, material: aluminium) |
Tyres | Front & Rear: Merida K1171 (700x40C, wire) |
Spokes | Steel UCP |
Max. Weight | 120 kg |
Geometry
Geometry of Merida Crossway 10 V Hybrid Bicycle
Frame Size | XS | S | M |
L |
Tyre Sizes | 28" | 28" | 28" | 28" |
Seat Tube [mm] | 390 | 430 |
470 |
510 |
Top Tube [mm] | 565 | 575 | 585 | 600 |
Chain Stay Length [mm] | 450 | 450 | 450 | 450 |
Head Tube Angle [°] | 71 | 71 |
71 |
71.5 |
Seat Tube Angle [°] | 74 | 73.5 | 73.5 | 73 |
Bottom Bracked Drop [mm] | 70 | 70 | 70 | 70 |
Head Tube [mm] | 135 |
140 |
140 |
170 |
Fork Length [mm] | 450 | 450 | 450 | 450 |
Reach [mm] | 391 |
394 |
404 |
404 |
Stack [mm] | 607 |
612 |
612 |
642 |
Wheel Base [mm] | 1073 | 1078 |
1088 |
1092 |
Stand Over Height [mm] | 592 |
590 |
592 |
590 |
Technologies
Technologies of Merida Crossway 10 V Hybrid Bicycle
Racelite 61 Aluminium: We use a minimum of 6061 grade aluminium on all our bikes. It’s particularly well suited to being shaped with our hydroforming and technoforming processes, which allow us to vary the wall thickness to create double-butted tubing and complex frame shapes. It’s also an alloy that welds easily, and once it has been carefully heat treated to maximise strength, it means we can create strong and lightweight bicycle frames for you to enjoy.
TFS - Techno Forming System: Manipulating the tube shape and thickness greatly impacts the appearance, weight and functionality of our aluminium frames. One technology that allows us to do that is Techno Forming, where plain aluminium tubes get mechanically formed by using an external form and an internal metal core. The result, beautifully shaped tubes with varying wall thickness, ready to be used to create our technoformed aluminium frames.
F-Mount: Being able to turn your bike into an all-weather commuter that has mudguards and other fittings can be a real plus, in particular when riding on wet and perhaps muddy roads and tracks on a regular basis. To make fitting easy, some of our bikes are F-Mount equipped. These integrated fittings mounts make adding mudguards fast and simple. Please note that some bikes require model-specific mudguards.
K-Mount: When using your bike in an urban environment, where you might not always have the option to use a specific bike stand, a kickstand is an ideal solution to park your bike safely. Some of our bikes come with a neatly integrated K-Mount, which makes fitting a Merida kickstand (or any commercial kickstand) easy. And if you don’t want to have a kickstand and prefer the clean appearance of your frame, the K-Mount is neatly tucked away underneath your chainstay, difficult to spot if you don’t know it is there.
C-Mount: Similar to our F-Mount, where various fixing points for mudguards are part of the frame offering, the C-Mount equipped bikes have the fixing points for a rear rack already integrated, making fitting fast, simple and reliable. The C-Mounts are an additional feature that improves the day-to-day versatility by adding loading capacity to your bike, ideal for commuting and shopping trips. Please note that some bikes require model-specific rear racks.
