Shimano Logo

Shimano Deore FC-M6120-1 1x12-Speed Front Chainwheel

EFCM61201CXA2
₹9,290
Length
Size

Trail-Ready 1x12 Crankset

Description

The Shimano Deore FC-M6120-1 crankset is designed for 1x12-speed mountain bike drivetrains, delivering seamless power transfer and reliable performance on rugged trails. Its direct-mount chainring construction ensures quick and easy installation, making it ideal for demanding riders.

Enhanced Chain Retention: Featuring a special gear tooth profile, the FC-M6120-1 enhances chain retention, reducing the risk of chain drops during aggressive riding. This ensures smooth and consistent pedaling even on rough and unpredictable terrain.

Boost Frame Compatibility: With a 178 mm Q-factor and a 55 mm chainline, this crankset is perfectly compatible with modern 148 mm O.L.D. Boost frames, ensuring optimal drivetrain alignment for efficient performance.

Lightweight and Durable Construction: The 2-piece crankset design combines lightweight performance with robust durability, making it a dependable choice for both trail enthusiasts and competitive riders.

Engineered for simplicity and performance, the Deore FC-M6120-1 crankset eliminates the need for a chain guard, offering a sleek and functional design tailored to today’s high-performance mountain bikes.

Features
  • Enhanced Chain Retention: Special gear tooth profile ensures smooth pedaling and reduces chain drops on rough terrain.
  • Boost Frame Compatibility: Designed for 148 mm O.L.D. Boost frames with a 55 mm chainline and 178 mm Q-factor for optimal drivetrain alignment.
  • Lightweight and Durable: 2-piece crankset construction offers robust durability with lightweight performance for aggressive riding.
  • Dynamic Chain Engagement+: Improves chain retention and pedaling efficiency, reducing wear for longer-lasting performance.
  • Direct Mount Design: Simplifies installation with a streamlined design for modern MTB drivetrains.

Technology

  • Dynamic Chain Engagement+: Special gear tooth profile enhances chain retention and engagement for smoother, more efficient pedaling on bumpy terrain.

Specifications
  • Model No: FC-M6120-1
  • Series: Deore
  • Color: Series Color
  • Rear Speeds: 12
  • Compatible Chain: HG 12-Speed
  • Chain Line (mm): 55
  • O.L.D.|Thru (mm): 148
  • O.L.D.|QR/Nut (mm): 141
  • P.C.D. (mm): Direct
  • Spider/Gear Arms: 4
  • Chainring Combination: 30T, 32T
  • Q-Factor (mm): 178
  • Crank Arm Length (mm): 165, 170, 175
  • Optional Chain Guard|Without Chain/Bash Guard: Yes
  • Crankset Type 2-Piece Crankset
  • Compatible Bottom Bracket Type|Outboard: Yes
  • Recommended Bottom Bracket|Threaded (Normal): BB-MT501
  • Recommended Bottom Bracket|Press-Fit: BB-MT500-PA
  • Threaded Bottom Bracket Shell Width (mm): 68, 73
  • Crank Fixing Screw Included: Yes
Shimano Warranty Information

Shipping Policy

We ship across India with free shipping on orders above ₹2,000 (₹99 for orders below ₹2,000). Cash on Delivery is available up to ₹20,000, with additional COD fees based on order value. Orders typically arrive within 3–6 working days, though delays may occur.

Note: Most Shimano products may take longer to ship. View full shipping policy

Returns & Refunds

Here's a quick overview of our return and refund policy:

  • 7-Day Return Window: You can initiate a return within 7 days of receiving your product.
  • Eligibility: Items must be unused, in original condition, with all tags and packaging. Only select items like apparel (helmets, jerseys, gloves, etc.) are eligible.
  • Non-Returnable Items: Wetsuits and items discounted over 5% are not eligible for returns.
  • Compatibility Issues: Returns are not accepted for compatibility-related issues unless the product description on our website was incorrect. If you're unsure, please contact us before ordering.
  • Shipping & Processing: Return shipping is to be arranged by the customer. No pickups available.
  • Refund Options: Choose between exchange, store credit, or monetary refund (after deductions for shipping and transaction fees).
  • Order Cancellations: Only possible before the order is processed.

For full details, visit our Return & Refund Policy page.

Shimano Deore FC - M6120 - 1 1x12 - Speed Front Chainwheel | The Bike Affair
Shimano

Shimano Deore FC-M6120-1 1x12-Speed Front Chainwheel

₹9,290

Length

  • 170mm

Size

  • 32T

Type

Crankset

Specifications

  • Model No: FC-M6120-1
  • Series: Deore
  • Color: Series Color
  • Rear Speeds: 12
  • Compatible Chain: HG 12-Speed
  • Chain Line (mm): 55
  • O.L.D.|Thru (mm): 148
  • O.L.D.|QR/Nut (mm): 141
  • P.C.D. (mm): Direct
  • Spider/Gear Arms: 4
  • Chainring Combination: 30T, 32T
  • Q-Factor (mm): 178
  • Crank Arm Length (mm): 165, 170, 175
  • Optional Chain Guard|Without Chain/Bash Guard: Yes
  • Crankset Type 2-Piece Crankset
  • Compatible Bottom Bracket Type|Outboard: Yes
  • Recommended Bottom Bracket|Threaded (Normal): BB-MT501
  • Recommended Bottom Bracket|Press-Fit: BB-MT500-PA
  • Threaded Bottom Bracket Shell Width (mm): 68, 73
  • Crank Fixing Screw Included: Yes

Features

  • Enhanced Chain Retention: Special gear tooth profile ensures smooth pedaling and reduces chain drops on rough terrain.
  • Boost Frame Compatibility: Designed for 148 mm O.L.D. Boost frames with a 55 mm chainline and 178 mm Q-factor for optimal drivetrain alignment.
  • Lightweight and Durable: 2-piece crankset construction offers robust durability with lightweight performance for aggressive riding.
  • Dynamic Chain Engagement+: Improves chain retention and pedaling efficiency, reducing wear for longer-lasting performance.
  • Direct Mount Design: Simplifies installation with a streamlined design for modern MTB drivetrains.

Technology

  • Dynamic Chain Engagement+: Special gear tooth profile enhances chain retention and engagement for smoother, more efficient pedaling on bumpy terrain.

The Shimano Deore FC-M6120-1 crankset is designed for 1x12-speed mountain bike drivetrains, delivering seamless power transfer and reliable performance on rugged trails. Its direct-mount chainring construction ensures quick and easy installation, making it ideal for demanding riders.

Enhanced Chain Retention: Featuring a special gear tooth profile, the FC-M6120-1 enhances chain retention, reducing the risk of chain drops during aggressive riding. This ensures smooth and consistent pedaling even on rough and unpredictable terrain.

Boost Frame Compatibility: With a 178 mm Q-factor and a 55 mm chainline, this crankset is perfectly compatible with modern 148 mm O.L.D. Boost frames, ensuring optimal drivetrain alignment for efficient performance.

Lightweight and Durable Construction: The 2-piece crankset design combines lightweight performance with robust durability, making it a dependable choice for both trail enthusiasts and competitive riders.

Engineered for simplicity and performance, the Deore FC-M6120-1 crankset eliminates the need for a chain guard, offering a sleek and functional design tailored to today’s high-performance mountain bikes.
